Condition : New
Free Shipping
Notify me when the price drops
We will email you if we find a lower price on this product!
SKU: G13365-03
Features:
> Zinc-plated, roll-formed steel components for durability.
> Precision, smooth-running synthetic roller carriages for quiet operation.
> Liquid damper for soft drawer closure.
> Self-latching front-locking devices with comfortable release levers for easy drawer removal and installation.
> Front locking device with height adjustment of 2.5mm (3/32").
> Positive tracked right side with ± 1.5mm (1/16") side tolerance on left side for precise alignment.
> Self-closing mechanism engages 30mm (1 1/4") before the closed position for a gentle stop.
> Weight capacity: 100 lb dynamic, 100 lb static for heavy-duty use.
> Meets and exceeds ANSI/BHMA 156.9, Grade 1 standards for quality and performance.
Specifications:
Drawer Length: 21" (533mm)
Nominal Length: 21-21/32" (550mm)
Minimum Installation Depth: 22-1/8" (562mm)
Max Installation Depth: 23-7/16" (596mm)
Drawer Thickness: 5/8"
.
